Production

Production environment.

Reference QR codes pointing at the production Branta environment (guardrail.branta.pro). See the parent page for what the variants mean.

Scanner: https://scan.branta.pro/scan?environment=production

Query param values in bitcoin: URIs are URI-encoded.

Strict privacy mode (the wallet default) won't resolve the plain On-chain or plain Lightning tabs — strict skips plain on-chain, and the SDK auto-encrypts Lightning invoices so a plain-text-only record produces no match. Use the ZK tabs to exercise a successful lookup in strict, or switch your SDK to loose mode to test the plain tabs.

On-chain

Open verify page

bitcoin:bc1qu3k6geqdjncaarsu2vq56tt8php5vsug9kasmq

Lightning

Open verify page

lightning:lnbc17760n1p4r4tqupp5yuapqmxldkc8smuwa6t8shkdg9gezulu0vc7htepfsvweph8kqfsdphgfexzmn5vysygetkv4kx7ur9wgsyc6t8dp6xu6twvusy27rpd4cxcegcqzzsxq97zvuqsp53564rg6w4xjqy7jamcfqxyy83a0j8nzfs0wpevs37t5ln49q6hrs9qxpqysgq47hpqmv34g25le8sceq9jdvul2nz7ucyu0vucv56nlfe40x7n3jsu8duxjrn6tgvdspt872crk9zeatafznm9c57m039z7wyx6g3njsqkchkdh

ZK On-chain

Open verify page

bitcoin:bc1q6745z6cy3u0k9nprurh3x804c4r7u3u8vxca2n?branta_id=z15b5EsbP5LHJrFco38%2BFp%2BHVaiopAY676NCKek8e1Q%2B4a370TyYhvloS8uLCUHfJ4CzeI%2FbOFmFDGpAQszB0gu1pJ1HOQ%3D%3D&branta_secret=c6e9eb30-6258-4432-9847-bdcc4fd4b0db

ZK Lightning

Open verify page

lightning:lnbc17760n1p4r4flypp5k56kq3v2935rl3glkqu9vngfueud2zj87hjcff3t0kn0yrge0pfqdzjgfexzmn5vysz6gzyv4mx2mr0wpjhygzvd9nksarwd9hxwgz6v4ex7gztdehhwmr9v3nk2gz90psk6urvv5cqzzsxq97zvuqsp5hut3t0l0s5mvp9yr06v4253kqtf452z6c65s6g9sga445hc03v6s9qxpqysgqqm430zkk9uymjgvllr3aha88hc6q59etxasfqswn8r8pfm3dstlpp46azv906xtcj3wzprxup5fxn65a5wymt7zzq9sw9qdzx8rgdhcpk80nrg

ZK Unified

The BIP-21 / BIP-321 shape POS like BTCPay emit on the on-chain tab when Lightning is also enabled: on-chain address + lightning= invoice + branta_id / branta_secret. Assembled from the ZK On-chain and ZK Lightning examples on this page. Pass the full URI to getPaymentsByQrCode — do not split it into one rail before lookup.

Open verify page

bitcoin:bc1q6745z6cy3u0k9nprurh3x804c4r7u3u8vxca2n?lightning=lnbc17760n1p4r4flypp5k56kq3v2935rl3glkqu9vngfueud2zj87hjcff3t0kn0yrge0pfqdzjgfexzmn5vysz6gzyv4mx2mr0wpjhygzvd9nksarwd9hxwgz6v4ex7gztdehhwmr9v3nk2gz90psk6urvv5cqzzsxq97zvuqsp5hut3t0l0s5mvp9yr06v4253kqtf452z6c65s6g9sga445hc03v6s9qxpqysgqqm430zkk9uymjgvllr3aha88hc6q59etxasfqswn8r8pfm3dstlpp46azv906xtcj3wzprxup5fxn65a5wymt7zzq9sw9qdzx8rgdhcpk80nrg&branta_id=z15b5EsbP5LHJrFco38%2BFp%2BHVaiopAY676NCKek8e1Q%2B4a370TyYhvloS8uLCUHfJ4CzeI%2FbOFmFDGpAQszB0gu1pJ1HOQ%3D%3D&branta_secret=c6e9eb30-6258-4432-9847-bdcc4fd4b0db

Not found

An unregistered destination. Use this to verify your wallet's 404 path — Branta returns no record, and the wallet should render nothing rather than show an error or block the send.

Open verify page

bitcoin:bc1qw508d6qejxtdg4y5r3zarvary0c5xw7kv8f3t4

Tampered

A QR code whose visible address has been swapped out while the branta_id/branta_secret still point at a legitimate, registered payment — the address in the bitcoin: URI is the "Not found" address above, but the ZK params are copied unchanged from the ZK On-chain tab. A correctly-integrated SDK detects that the address it decrypts doesn't match the address in the QR and rejects the lookup instead of returning it as verified — use this to confirm your wallet treats a mismatch as a hard stop, not a missed/not-found lookup.

Open verify page

bitcoin:bc1qw508d6qejxtdg4y5r3zarvary0c5xw7kv8f3t4?branta_id=z15b5EsbP5LHJrFco38%2BFp%2BHVaiopAY676NCKek8e1Q%2B4a370TyYhvloS8uLCUHfJ4CzeI%2FbOFmFDGpAQszB0gu1pJ1HOQ%3D%3D&branta_secret=c6e9eb30-6258-4432-9847-bdcc4fd4b0db
